Tape Deck à cassette Teac V-900 X

600.-

16.07.2026

2300, La Chaux-de-Fonds

Appareil de 1986 révisé et pleinement fonctionnel avec manuel.
voir audiovintage.fr/leforum/viewtopic.php?t=55008

Manufacturer: Teac
Model: V-900 X
Type: Cassette Tape Deck
Years of manufacture: 1982 - 1987
Made in: Japan
Color: Black
Remote control: yes, RC-203
Power consumption: 38 W
Dimensions: 432 x 114 x 327 mm (WxHxD)
Weight: 7,5 kg
Original price approx.: 1'800 DM

Connections
Number of inputs:
Line In: 275 mV, 50 kOhm
Line In DIN: 60 mV, 50 kOhm

Microphone: 0.25 mV, > 200 Ohm
Number of outputs:
Line Out: 435 mV, 50 kOhm
Line Out DIN: 30 mV, 50 kOhm

Headphones: 4 mW, max. 8 Ohm

Technical Data
Audio heads: 3 TEAC CA audio heads made of amorphous cobalt
Recording: 1 amorphous cobalt
Playback: 1 amorphous cobalt
Erase: 1
Motors: 3
Recording/playback: DC FG servo for direct drive Capstan.
Coils: DC Coil Motor
Cassette compartment: 1 control motor
Synchronisation fluctuations: < 0.028 %
Tape types:
Frequency response:
Normal: 30 - 19'000 Hz, ± 3 dB.
Chrome: 30 - 20'000 Hz, ± 3 dB
Metal: 30 - 21'000 Hz, ± 3 dB

Distortion factor: 2.5
Signal-to-noise ratio:
Dolby Off: 60 dB (1 kHz)
Dolby B On: 70 dB above 5 kHz
Dolby C On: 80 dB over 1 kHz
DBX On: 92 dB over 5 kHz
Dolby B, C, DBX (1 kHz)
DBX Dynamic Range: 110 dB (1 kHz)
Pre-magnetization and erase frequency:
Rewind time: 90 seconds for C-60 cassette.

Special Features
Automatic calibration device
